Hotels, Machinery Repair Shops, Food & Beverage Factory, restaurant, HOME USE, Food Shop, Energy & Mining, Food & Beverage Shops
Place of Origin:
380V/50Hz/3Phase or other
After-sales Service Provided:
Field installation, commissioning and training, Field maintenance and repair service
Germany Bitzer / America Copeland
2. Solenoid valve:
Italy brand Castal
3. Electrical components:
Korea brand LG
4. PLC program:
Germany brand Siemens
5. Ice machine framework:
Stainless steel 304
6. Cube ice size:
22mmx22mmx22mm or 29mmx29mmx22mm
R22 or R404a
8. Cooing way:
Water cooling, air cooling, evaporative cooling
30 Set/Sets per Month Cube Ice Maker
Packaging & Delivery
1. Standard wooden case.
2. Completely ice machine contain: ice machine, cooling tower, water pump, water pipes and water pipe fittings.
3. Machine come into use, customer only need prepare power for the machine.
4. All required components for install the machine will be provide
Nansha or Huangpu Port(Guangzhou, China)
1 - 1
To be negotiated
CBFI CV1000 1 Ton Per Day Cube Ice Machine With Automatic Control
Sanitation & Safety: Fully adopted SUS304 stainless steel to build this machine; special water flow design, automatic cleaning, sanitary, safe, and fulfills the demand of QS test standard.
Low energy consumption: 85~90 kWh/ton in summer, 70~85 kWh/ton if the ambient temperature is lower than 23℃.
Large capacity: Single machine’s daily capacity can be 1 ton to 20 tons and production is stable, in hot summer we can still reach 90~95% of the rated capacity. If the ambient temperature is lower than 20℃, it can reach 100~130%.
Stable performance: Ice is crystal clear and hard, well-shaped and beautiful, can be stored for a long time.
Components brand: Compressor is German Bitzer or Italian Frascold, electric devices are Siemens or LG.
Ice cube size: 22*22*22mm / 29*29*22mm / 38*38*22mm or customized.
Automatic operation: PLC controlled, be able to automatically adjust the thickness of ice, forming ice, harvesting ice, and add water.
Fully automatic and need no human adjustment.
Ice source cube ice machines are widely used in hotels,restaurants,bars,fast-food shops,supermarkets and cold drink shops, etc. Icecource ice machine are highly efficient,energy saving,safe and environmentally friendly andd quickly becoming the most popular choice for clients around the world.
1 ton per day Large Capacity Cube Ice Machine for hotels & restaurants Parameters
Daily output (T/24h)
Fan Power for Cooling Tower
Cooling Pump Power
♦ Size of cube ice:22*22*22mm / 29*29*22mm / 38*38*22mm ♦ Compressor Brand: Bitzer / Frascold; Refrigerant: R22/R404A; Cooling Method: Water Cooling / Air Cooling; ♦ Power Supply: Voltage 380V/3P/50Hz (For non-standard voltage, unit configuration needs to be calculated separately). ♦ Operating Conditions: T(water supply) : 20 ° C, T(ambient) : 32 ° C,
T(condensing) : 40 ° C,T(evaporating):-10℃.
Why should I choose CBFI large cube ice machine instead small commercial machines?
(1) The small-capacity ice-making machine has a small daily output and cannot meet the market demand;
(2) Small-scale edible ice-making machines consume high electricity, and consume 160kw of electricity per ton of ice;
(3) The capacity of small-scale edible ice-making machines is relatively low. When the ambient temperature is high, the climate is hot and can not reach the standard;
(4) The cooling water of the small-scale edible ice machine cannot be recycled, resulting in waste of water;
(5) The small-scale edible ice machine still stays in manual operation, and the intelligent operation is low;
(6) The small service life of small-sized ice-making ice machines is also a major drawback;
Guangzhou Icesource Co., Ltd. (trademark CBFI), a pioneer in the large-scale fluorine refrigeration and ice making equipment industry, is an innovative and entrepreneurial high-tech enterprise that integrates research, design, manufacture, sales, and after-sales .The main products are block ice machine, tube ice machine, cube ice machine, flake ice machine, plate ice machine, cold room, intelligent cold room unit, ice machine supporting equipment and fully automated ice plant. Products are widely used in food, retail, fruits and vegetables, aquatic products, chemicals, medical, construction, minerals and other fields for cooling, storage and preservation.
The company was established in 2010, and the research and development started in 2004. Since the establishment of the company, it has continuously increased investment in product research and development. All sales products are independent research and development products. By April 2018, there were 2 invention patents, 21 utility model patents, 1 appearance patent, and 9 invention patents and 6 utility model patents are under examine and verify.
1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts, operation manual and CD are provided to guide the installation.
2).Installing by our engineers:
(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.
(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready. Meanwhile, we will provide you a Tool List with the machine when delivery.
(3) All spare parts are provided according to our standard. During installation period, any shortage of parts due to the actual installation site, the buyer is required to afford the cost, such as water pipes.
(4) 2~ 3 workers are required to assist the installation for big project.
1.Q: are you add refrigerant in the ice machine?
A: yes, the machine is full of refrigerant, once with water and electric it can work. yes, ice machine leaves factory with carefully examination after it was produced for 3 to 5 days. And when we install them at customer’s factory, we retest the ice machines.
2.Q:do you test the ice machine in your factory?
A: yes, ice machine leaves factory with carefully examination after it was produced for 3 to 5 days. And when we install them at customer’s factory, we retest the ice machines.
3.Q: can you load ice machine into container?
A: we have containerized ice block machine. Our export ice machine is designed based on the standard of container, it is easily to load. The 25kg ice of 10tons can load in container of 40 feet. for domestic ice machine of over 12 tons per day, we design based on the standard of truck, which can easily drive into your factory.
4.Q: all your ice machine is based on 380V 50HZ power requirement? Do you have the right power requirement for abord? Such as 440V 60HZ or 220V three phase that suitable for America?
A: our ice machine and power,voltage can suitable for your country, please make the power requirement be clear in your order.
